1. Specially for clinic\ ward photography.
2. Flexible mobile operating performance.
3. Wireless remote exposure, greatly reduces the radiation dose of doctors.

Power Supply:

1. Supply Voltage: AC 220V±22V.
2. Power supply allows maximum internal resistance: 1Ω.
3. Power frequency: 50Hz±
4. Power Capacity: ≥

Photography condition:

1. Tube voltage: 40-90kV, 5kV per file.
2. Tube current: 30mA, 50mA.
3. Time: 0.05s－

Mechanical behavior:

1. When the X-ray generator window is down, the distance between the focus and the ground is 450mm~1770mm.
2. The angle of the X-ray generator around the horizontal axis is ±180º.
3. The X-ray generator rotation angle around vertical axis is ±90º.

Overall dimensions (length x width x width): 1290 x 630x 1935mm
