Interface and digital screen of FHR, TOCO, FM;
Type: 7” Color TFT LCD, adjustable
Resolution: 800*480
Built-in thermal recorder, 110*100mm
Print speed: 1, 2, 3 cm/min

1. light and compact design, simple to use front panel controls
2. 7 TFT Color screen, folding 90 degree
3. The system setup can be done very easy and can be stored automatically
4. The internal line thermal printer can records FHR, TOCO, the life exceeds over 20years
5. A standard patient event marker and a clinical event marking button to separately mark Clinical events
6. Auto Fetal movement are available
7. Multi-crystals, wide beam form, high sensitivity ultrasound transducer, low ultrasound power, Safer to the fetal
8. AC or LI-battery operated
9. More than 42 hours data storage, then can be played and reprinted
10. Build-in interface to the central nurse station

Fetal Heart Rate (FHR)
Parameters: FHR1, FHR2 (optional)
Measurement range: 50 – 240 bpm
Accuracy: ±2 bpm;
Sweep speed: X1, X2, X4, X8

Transducer
9 crystals, pulsed Doppler, high sensitivity
Frequency: 1.0MHz
Probe: wired

Uterine Activity (TOCO)
Measurement range: 0 – 100
TOCO baseline: 0, 5, 10, 15, 20 (selectable)

Weight & Dimensions
Net Weight: 1.75kg
Dimensions: 295(D)*240(W)*75(H) mm

Standard Accessories
FHR.TOCO, FM Transducer
2 pcs of printer paper.
One power cable
Two bandages /three bandage (twin optional)
Second one transducer(optional)

Remark
3 Para (fetal monitor): FHR, TOCO, FM
6 Para (fetal/maternal monitor): FHR, TOCO, FM, MHR, SPO2, NIBP

Options
Twins Probe, Fetus Waker, Touch Screen, Trolley, Wall Bracket
