-10″ TFT display , 90 degree foldable.
-Built-in longtime 110mm thermal printer
-Super sensitive probe.
-Longtime data storage and printout.
-Rechargeable battery support longtime working.
-DSP technology, realtime identifying and measurement of FHR, accurate and reliable results.
-Automatic Fetal Movement Detection and Accounting.
-CTG scoring system: Krebs score/Fischer Score

-FHR working frequency: 1.0 MHZ
-Transducer: Multi-crystals, wide wave beam, pulsed-wave working mode
-Strength: <5mW/cm2
-TOCO range: 0-100 units
-Display: 10″ display
-Dimension:295D X 250.5W X 81.5H mm
-Option: Twins FHR measurement, Maternal SPO2. PR, NIBP

Fetal Heart Rate (FHR)
Parameters: FHR1, FHR2 (optional)
Measurement range: 50 – 240 bpm
Accuracy: ±2 bpm;
Sweep speed: X1, X2, X4, X8

Transducer
9 crystals, pulsed Doppler, high sensitivity
Frequency: 1.0MHz
Probe: wired

Uterine Activity (TOCO)
Measurement range: 0 – 100
TOCO baseline: 0, 5, 10, 15, 20 (selectable)

Weight & Dimensions
Net Weight: 1.75kg
Dimensions: 295(D)*240(W)*75(H) mm

Standard Accessories
FHR.TOCO, FM Transducer
2 pcs of printer paper.
One power cable
Two bandages /three bandage (twin optional)
Second one transducer(optional)

Remark
3 Para (fetal monitor): FHR, TOCO, FM
6 Para (fetal/maternal monitor): FHR, TOCO, FM, MHR, SPO2, NIBP

Options
Twins Probe, Fetus Waker, Touch Screen, Trolley, Wall Bracket
