1. LED blue bulbas the radiant source is irradiating uniformly and efficient
2. Circle 360°double sides for more effective radiation
3. With side door so that the infant bed can be pulled out, convenient for the clinician.
4. With mute slide rail and damping system to make sure the moving of the infant bed smooth and silently
5. Infant bed can be dismantled, easy for cleaning and disinfection
6. Two phototherapy mode: upside and downside phototherapy, can be use separately
7. Therapy time of phototherapy units from up and down side are displayed separately
8. Automatically record each therapy time and total used therapy time
9. Air temperature and skin temperature separately display
10. Power off memory, alarm silence key, locking key and self-examination function
11. Four alarm functions: Power Failure, Probe Failure, Over Temperature, Fan Failure
12. Count-down setting available
13. Two sides observation parts
14. Air spring structure make the hood is easy open and close
15. The aluminum alloy is applied on the base, with 2 drawers and 1 tray

Performance

Power supply: AC220V±10%, 50Hz±2%

Power input: 300VA

Blue light wavelength: 420mm ~ 490mm

Circle 360 light radiation: 5000μW/cm², 83μW/cm²/nm

Downside light radiation: 4200μW/cm², 70μW/cm²/nm

Life span of blue light tube: 50000hours

Air Temperature display range: 0 ~ 45°C

Skin Temperature display range: 30 ~45°C

Time accuracy: 1min/2h

Count-up time range: 0 ~ 99.9 hours

Count-down time range: 1min ~ 99.9 hours

Total cumulative time: 999999 hours

Mattress size: 613*300mm

Working Environment

Ambient temperature: +18°C ~ +30°C

Relative humidity: 10% ~ 85%

Atmosphere pressure: 700hpa ~ 1060hpa

Transport and Storage Environment

Environment temperature: -10°C ~ +55°C

Environment relative humidity: ≤95%

Atmosphere pressure: 500hpa ~ 1060hpa

Standard Configuration

Main body (including the radiant source, control system, infant bed, bracket), IV pole, skin temperature sensor, air temp sensor, tray, mattress, transparent protector, castors, two drawers.

Option Parts

Gel Mattress

Package

Each unit is packed in one case

PKG Dimension: 90*77*132cm

N.W.:60Kg G.W.:90Kg
