-Ultra-low design.
-The bed surface is made of high-quality carbon plastic board, and the table surface can be moved longitudinally to meet the needs of C-arm whole body inspection and filming.
-The mattress is made of imported artificial leather wrapped with high-density memory foam and formed at one time with no seam.
-There are two control modes: hand-held remote controller and panel controller, with self-locking function.
-With one-key forming and “v” shape, it is convenient for operation.
-The complete hydraulic system adopts the German HO ERBIGER brand.
-AC and DC, CPU control, with one-key reset function.
-The countertop support frame, the rails on both sides and its accessories are all made of high-quality 304 stainless steel, and the base and column cover are made of stainless steel for one-time molding.
-Electric brake device facilitates the displacement of the operating table.
-The head and leg plates are controlled by imported gas springs, and the leg plates are split and detachable.
PARAMETER | SPECIFICATION |
Length | 2000±100mm |
Width | 520±20mm |
Height Adjustment | (650-1100) ±50mm |
Tilt (left) | ≥20°; Tilt (right)≥20° |
Trendelenburg | ≥30°; Rev-Trend≥30° |
Head Board Upward | ≥50°; downward≥90° |
Back Board Upward | ≥70°; downward≥40 |
Leg Board Upward | ≥20°; downward≥90° |
Leg Board Outwards | ≥180° |
Lumbar Upper Corner”∧” | ≤150° |
Lumbar lower Corner”∨” | ≤110° |
Waist Board Lifting | 100±20mm |
Horizontal and longitudinal movement | 400±30mm |
Mains Voltage | AC220±22V, 50±1Hz |
Input Power | 400±10%VA |
Shoulder Support—-1pc
Waist Support—-1pc
Arm Support—-2pcs
High-level Arm Support—-1pc
Leg Support—-2pcs
Screen—-1pc
